CAMUS UGR19 25W-IP44-4000K-WHITE

Data sheet

Yes

Yes

IP

IP20, IP44 facade

IRC

>80

Dimmable

Non

IK

IK08

Energy efficiency class

E

Warranty (years)

5

Total power (W)

25

Electric class

III, II with power supply

Power factor

>0.9

Rated voltage

230V

Light beam spread (°)

90

Luminous flux (lm)

3050

Color temperature

4000K

Safety group (EN62778)

RG0

Unified Glare Rating (UGR)

< 19

Driver included

Yes

Including the light source

Yes

Light source type

SMD

Tiltable

Non

Height (mm)

13

Weight (kg)

0.75

Min. recessed diameter (mm)

220

Max. recessed diameter (mm)

235

Recessed diameter

233, 234, 235, 220, 221, 222, 223, 224, 225, 226, 227, 228, 229, 230, 231, 232

Product color

White

Use temperature range

-25°... +40°C

Connection type

Fil à connecter

IP (value)

20, 44

Body materials

Aluminium

Diffuser materials

PC

Life span duration

L80 à 25° : 50 000 h

Cable length

10 cm

Recessed depth under BA13 (mm)

35

Recoverable

Non recouvrable

Network frequency

50Hz

Initial SDCM

SDCM< 4
