SURFACE SQUARE 10W-3CCT-IP20-DIM-BLACK
  • SURFACE SQUARE 10W-3CCT-IP20-DIM-BLACK
  • SURFACE SQUARE 10W-3CCT-IP20-DIM-BLACK
  • SURFACE SQUARE 10W-3CCT-IP20-DIM-BLACK
  • SURFACE SQUARE 10W-3CCT-IP20-DIM-BLACK

SURFACE SQUARE 10W-3CCT-IP20-DIM-BLACK

BL05102003
LED ceiling light easy to install. Adjustable 20-90 and 3 CCT! Dimmable, this luminaire gives perspective to your hallways, kitchens, bedrooms
create a modern and friendly atmosphere
BL05102003
BE-LED

Data sheet

IP
IP20
IRC
>90
Dimmable
Yes
IK
IK06
Energy efficiency class
D
Warranty (years)
5
Total power (W)
9.5
Electric class
I
Power factor
>0.9
Rated voltage
230V
Light beam spread (°)
60
Luminous flux (lm)
800, 875
Color temperature
4000K, 3000K, 5000K
Safety group (EN62778)
RG1
Driver included
Yes
Including the light source
Yes
Light source type
COB
Tiltable
Yes
Length (mm)
90
Width (mm)
90
Height (mm)
110
Weight (kg)
0.52
Product color
Black
Use temperature range
-25°... +45°C
Connection type
Connector on the product
IP (value)
20
Body materials
Aluminium
Diffuser materials
PC
Life span duration
L70 à 25° : 50 000 h
Recoverable
Non concerné
Dimmable values
Triac
Tilt angle
30
Network frequency
50Hz
Initial SDCM
SDCM< 5
